7 models

Direct thermal printer ZQ630 Plus RFID Zebra; English fonts, Dual 802.11AC / BT4.x, Linered platen, 0.75" core, Group E, Shoulder strap, Belt clip

Cat. no.: ZQ63-RUWAE14-00

Price: €1 774.70

SRP: €2 431.60

Save up to €656.90

Media types

Die-cut labels and tags, linerless labels, receipt paper, RFID (compatible with ZQ630/ZQ630 Plus RFID printer), black mark sensor, gap sensor Die-cut labels and tags, receipt paper, RFID (compatible with ZQ630 Plus RFID printer), black mark sensor Note: ZQ630 Plus RFID requires media with black mark and does not support gap detection

Display

Not Yes

Rfid

Not Yes

Movable Label Sensor

Not Yes

WIFI

Not Yes

RS-232

Not Yes

Compare all parameters

Availability 5-6 days in stock

Other configurations ZQ630 Plus 7 models

You are planning a major purchase, carrying out a project, Find out more.

Features

Producer:

Zebra

catalog No.: ZQ63-RUWAE14-00

Printer specification
Print methods	direct thermal
Printing resolution	203 dpi
Print speed	115 m/s
Maximum print width	104 mm
Maximum print length	813 mm
Maximum label width	51 mm
Maximum label width	112 mm
Minimum label length	12,7 mm
Maximum label length	813 mm
Label roll outer diameter	66 mm
Label roll inner diameter	19 mm
Label thickness	Tags 0.081 mm to 0.14 mm or labels 0.190 mm
Media types	Die-cut labels and tags, receipt paper, RFID (compatible with ZQ630 Plus RFID printer), black mark sensor Note: ZQ630 Plus RFID requires media with black mark and does not support gap detection
Memory	RAM 256 MB; Flash 512 MB (Standard)
Programming languages	EPL, ZPL, CPCL
Supported codes	Bar ratio: 1.5:1; 2:1; 2.5:1; 3:1; 3.5:1. Linear barcodes: Code 39, Code 93, UCC/EAN128, Code 128, Codabar (NW7), Interleaved 2 of 5, UPC-A and UPC-E, 2- and 5-digit extensions, EAN-8, EAN-13, 2- and 5-digit extensions. 2D barcodes: PDF417, MicroPDF417, MaxiCode, QR codes, GS1/DataBar™ (RSS) family, Aztec, MSI/Plessey, FIM Postnet, Data Matrix, TLC39
Software	ZBI 2.x™ – advanced programming language enabling printers to run standalone applications, connect to peripheral devices, and much more
Display	Yes
Rfid	Yes
Movable Label Sensor	Yes
Battery	Removable PowerPrecision+ rechargeable lithium-ion battery, 6800 mAh (nominal), 49.4 Wh
Resistance	Resistance to multiple drops onto concrete from a height of 1.83 m. IP54 ingress protection rating ensuring resistance to water and dust. Compliance: EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, and EN61000-4-5. Display made of tempered glass and seamless construction. The high-grade resin used in their production is one of the hardest available materials, providing increased impact resistance
Interfaces
Interface	Bluetooth, USB, WiFi, RS232
Bluetooth	Yes
USB	Yes
WIFI	Yes
RS-232	Yes
NFC	Yes
Physical specification
Color	black
Warranty	12 months
Dimensions	187 mm x 165 mm x 82,5 mm
Weight	1,1 kg with battery
Performance specification
Operating temperature	-20° to 50°C
Storage temperature	-25°C to 65°C
Operating humidity	10% to 90%, without condensation
Storage humidity	10% to 90%, without condensation
