Handheld scanner Zebra DS3608, 66 cm, ethernet, high density

Cat. no.: DS3608-HD3RF50BZVW

Price: €954.10

SRP: €1 036.00

Save up to €81.90

Scanner type

Imager 2D, 1D Imager 2D, 1D, DPM

Decode ranges

to 152 cm 203 cm 66 cm 7,6 cm - 21 m 0,5 - 14,7 cm (depending on the code)

Decode range type

SR ER

Cable

not included cable USB ethernet USB

Presentation cradle

Not Yes

High density

Not Yes

DPM metal laser etch

Not Yes

Compare all parameters

Availability Make a phone call +48 668 949 599

Other configurations DS3608 18 models

Make a phone call +48 668 949 599

You are planning a major purchase, carrying out a project, Find out more.

Eliminating third-party converter boxes and related equipment from the system removes a point of vulnerability on the network. When scanners are connected directly to the PLC it creates a more secure data capture environment.

3600 Series scanners can now connect directly to the PLC system which eliminates unnecessary networking equipment from the setup and reduces the risk of unplanned downtime due to process failure

Network Connect accommodates popular Industrial Ethernet Protocols so programmers don’t have to spend time making complex protocol conversion systems work. Seamlessly integrate Network Connect with a proprietary PLC and instantly remove the errors that can occur with an extra layer of third-party equipment on an industrial network.

Easy connection to PLC networks for all 3600 Series scanners

Purpose-built for the plant floor

Features

Producer:

Zebra

catalog No.: DS3608-HD3RF50BZVW

Interfaces
Interface	USB
Bluetooth	Yes
USB	Yes
Physical specification
Color	Industrial green, black
Warranty	36 months
Dimensions	76.2 x 185.4 x 132.1
Weight	304 g
Performance specification
Operating temperature	-30 st. C to 50 st. C
Storage temperature	-30°C to 50°C
Operating humidity	5% to 95% without condensation
Storage humidity	5% to 95% without condensation
Electrical characteristics	Power from base device: 4.5 VDC (min.) to 5.5 VDC (max.); External power supply: 11.4 VDC (min.) to 12.6 VDC (max.)
Scanner specification
Compatible codes	1D Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 z 5, koreański 3 z 5, GS1 DataBar, Base 32 (włoski Pharmacode) 2D PDF417, MicroPDF417, kody złożone, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, MicroQR, Chinese Sensible (Han Xin), pocztowe
Scanner type	Imager 2D, 1D
Decode ranges	66 cm
Feedback	Bezpośredni wskaźnik odczytu, diody LED, sygnał dźwiękowy, wibracja
Decode speed	b/d
Required code contrast	Minimalny współczynnik odbicia: 15%
Fall resistance	Resistance to multiple drops to concrete from a height of 2.4 meters
IP norm	Scanner: IP65 i IP67; base station FLB: IP65
Cable	ethernet
High density	Yes
